Oase BioTec ScreenMatic 60000. (57695)

Description

Oase Biotec Screenmatic2 60000

OASE German Engineers have completely overhauled the highly successful BioTec 18 ScreenMatic filter and have released the innovative BioTec ScreenMatic² 60000 Pond Filter. This compact gravity outlet, flow-through filter box features an automated pre-filter conveyor which will screen out larger debris and transport this on a porous conveyor belt to a large collection basket for periodic emptying. The new Screendrive mechanism is now fully automated via a special cleaning sensor which controls the belt functions depending on the dirt level detected on the porous belt. Only small particles pass through the ScreenMatic drive belt where the large surface area biological/mechanical filter foams will trap and break down the organic waste. This innovative mechanism places far less biological load on the filter foams, meaning less maintenance and crystal clear water quality in ornamental, Goldfish and Koi ponds alike.

The OASE BioTec ScreenMatic² 60000 is an intelligent, flow-through pond filter that provides automated mechanical waste removal and biological filtration. The water enters the filter via a flow spreader onto a 300 micron fabric belt which strains out solid waste particles. When sufficiently soiled, a sensor engages the motor which performs a cleaning cycle, transferring the accumulated waste into a collection tray below the screen. The control display also allows instant cleaning cycles at the press of a button. The waste sensor can be adjusted backward and forward to alter cleaning regularity based on waste accumulation. A cleaning brush is supplied to keep the fabric screen free of entrapped dirt.

After mechanical straining, water enters the the biological media, a series of 8 large filter sponges differing in coarseness. The blue foams are rough, violet are medium fine and red are very fine grade. These sponges provide an abundance of surface housing for aerobic bacteria to populate and breakdown soluble waste pollutants. Cleaning the foams is made easy by the compression handle used to push down on the foams to release any build up of organic waste. Water is then directed through cartridges containing 3.5kg of granulate media (zeolite) which bind unwanted nutrients and trace ammonia before returning water to the pond.

Incl. OASE Clear Water Guarantee
Significantly less maintenance is required, thanks to coarse debris extraction
More convenience, thanks to automatically driven self cleaning of the belt filter. Adjustable cleaning Sensor controls the belt run, depending on the degree of pollution. Incl. LED function check
Cleaning of filter sponges directly in the filter, without removal
Sludge drain with slide valve for removing debris from the filter system
Different filter media for optimal development of filter bacteria
Use of the PhosLess filter media tubes as needed for string algae reduction (optional accessory)
Optimally matched to OASE AquaMax Eco filter pumps
Direct connection possibility for Bitron C and Eco UVC clarifiers
Reinforced strap material for an extended service life
Double-sealed motor for an extended service life
Water distributor without danger of clogging: Distributes the water uniformly on the belt filter
Sludge basket with greater volume and simplified handling
Rubberised separating lip for outstanding separation result
Free brush for occasional cleaning of the belt filter
Manual belt run now possible via button
Highly effective flow-through filter for ponds up to 60.0 m³
Lids of models 40,000 and 60,000 with storm-safe fastening clips

Dimensions (L x W x H) mm 788 x 590 x 545
Rated voltage (primary, secondary) 230 V / 50 Hz, 12 V / AC
Power consumption W 5
Cable length 12 V device (with power unit) m 2.10 (Power unit) + 5.00
Net weight kg 23.50
Guarantee Years 2 + 1
Number of filter foams, total Units 8
Number of blue filter foams Units 2
Number of red filter foams Units 3
Number of purple filter foams Units 3
Special filter granulate kg 3.50
Temperature display No
Coarse debris extraction µm 300
Inlet connections mm 25 / 32 / 38
Inlet connections 1″, 1 ¼”, 1 ½”
Outlet connections DN 75
Sludge discharge connections DN 50
Min. flow rate l/h 6000
Max. flow rate l/h 11000
Suitable for ponds up to max. m³ 60.0
Suitable for ponds with fish stock m³ 30.0
Suitable for ponds with koi stock m³ 15.0
Connection to Bitron C 36 – 110 W, Bitron Eco 120 – 240 W
